Motor BetaFPV Lava 1104 7200KV
Motor BetaFPV Lava 1104 7200KV

29.00 AUD

(price per motor)

4 in stock


1104 size motors at 7,200KV are a good choice for 3S builds. Motors between 6,500KV and 7,000KV are commonly used in 2 inch Cinematic drones with either 3 or 4 blade props. (see examples)

LAVA Series 1104 | 7200KV Brushless Motors is designed for the 3S 2.2” quads, with smoother torque output performance. Ensuring enough creative space for cinewhoop to explore and capture the most imaginative aerial feats, easily meet professionally shot film creation needs, leading the 3S 2.2” quads for cinewhoop to new heights.

Bullet Point

  • Unleash the power of freestyle with the LAVA Series 1104 | 7200KV motors, precision-engineered for 3S 2.2” quads. Experience a quantum leap in performance, taking the Pavo20 Pro Brushless Whoop Quadcopter freestyle experience to new heights.
  • With the lower pitch Gemfan 2218 3-Blade Propellers, the max thrust can reach more than 230g, achieving a thrust-to-weight ratio greater than 5:1, delivering a faster and more agile freestyle experience.
  • Paired with the above GF props, the force efficiency is as high as 4.7g/w when flying at low throttle, and even at full throttle load conditions, it can reach 1.9g/w, providing an efficient propulsion system for the quad.

The picture below is the diagram of the LAVA Series 1104 | 7200KV Brushless Motors(80mm).



Specifications

  • Items:  LAVA Series 1104 | 7200KV Brushless Motors
  • Maximum Power: 122.5W
  • Maximum Current: 10.2A
  • Weight: 5.3g
  • Shaft Diameter: ø1.5mm
  • Shaft Length: 5mm
  • Wire Specification: 28AWG
  • Wire Length: 24/80mm
  • Motor Mounting Hole Size: 4*M2 Ø9mm
  • Propeller Mounting Hole Size: 4*M2 Ø5mm





Package

  • 1 * LAVA Series 1104 | 7200KV Brushless Motors
  • 4 * M2 * 4 Hex Flat Head Screw
  • 4 * M2 * 5 Hex Flat Head Screw



FPV Motor Sizes Guide FPV Motor Volume Guide
See this Motor Size Guide for information on what sizes of motors are used in popular BNF and PNP FPV drones. See this Motor Volume Guide for information about what other motor size is similar to the one you are looking for.
